ViewSonic N3235w / N3735w 16
ENGLISH
Contact ViewSonic service team at: http://www.ViewSonic.com or call our service team: United States 1-800-688-6688, Canada 1-866-463-4775
Getting Started
Item Description
10 HDMI 1 signal Audio input
(left/right)
Connect this port to the RCA audio output connectors of your
A/V device.
11 YPbPr 2 signal Audio
input (left/right)
Connect this port to the RCA audio output connectors of your
A/V device.
12 YPbPr 1 signal Audio
input (left/right)
Connect this port to the RCA audio output connectors of your
A/V device.
13 AV/ S-Video signal Audio
input (left/right)
Connect the audio cable for AV or S-Video to this connector.
14 Audio output Connect this port to your A/V device with audio in (RCA)
connectors or to audio amplifier.
15 Headphone Jack Connect to your headphones. By connecting the headphones,
you can listen to the sound from the TV on headphones.
＊
If you connect the headphones, the TV speakers will be
muted.
16 VGA/ HDMI 2 Audio input Connect this port to PC line out jack.
17 SPDIF Optical output
Connect this port to the SPDIF input of A/V device.
Note: There is a Service jack next to the HDMI Input Terminal
[2]. It is for service technician’s use.
AV connection
Connect the composite video and audio input jacks to the corresponding output jacks of your
A/V device.
--- VIDEO: Composite Video input [7]
--- AUDIO: AV/ S-Video signal Audio input [13]
S-Video connection
Connect the S-Video and audio input jacks to the corresponding output jacks of your VCR or
other video device that has S-Video. S-Video provides better picture quality than composite
video connection. If both are connected, S-Video signal has priority.
--- VIDEO: S-Video input [8]
--- AUDIO: AV/ S-Video signal Audio input [13]
