Page 17
Connections
Before making connections:
7
First turn off the power of all the attached equipment and make connections.
7
Refer to the user manual included with each separate piece of equipment.
Wiring Diagram
DVD
LCD monitor (second monitor)
HD
Equipment with
Digital interface
PC
VCR
ViewSonic
CD4220
15
