Vivotek SD7151 - Manual (Page 87)

VIVOTEK - A Leading Provider of Multimedia Communication Solutions
User's Manual - 87
Group: media_i<0~4>
Name Value
Security
(get/set)
Description
name string[40] 6/6 The identification of this entry
type
snapshot,
systemlog,
videoclip
6/6 The media type to send to the server or store by the server.
snapshot_source 6/6
Indicate the source of media stream.
0 => the first stream.
1 => the second stream and etc.
snapshot_prefix string[16] 6/6 Indicate the prefix of the filename.
snapshot_
datesuffix 0,
1
6/6
To add date and time suffix to filename or not.
1 => to add date and time suffix.
0 => not to add it.
snapshot_
preevent
0~7 6/6 It indicates the number of pre-event images.
snapshot_
postevent
0~7 6/6 The number of post-event images.
videoclip_source 6/6
Indicate the source of media stream.
0 => the first stream.
1 => the second stream and etc.
videoclip_prefix string[16] 6/6 Indicate the prefix of the filename.
videoclip_
preevent
0 ~ 9 6/6 It indicates the time of pre-event recording in seconds.
videoclip_
maxduration
1 ~ 10 6/6 The time of maximum duration of one video clip in seconds.
videoclip_
maxsize
50 ~ 1500 6/6 The maximum size of one video clip file in Kbytes.
Group: recording_i<0~1>
Name Value
Security
(get/set)
Description
name string[40] 6/6 The identification of this entry
enable
0,
1
6/6
To enable or disable this recoding.
0 => Disable
1 => Enable
priority
0,
1,
2
6/6
Indicate the priority of this recoding.
0 => low priority.
1 => normal priority.
2 => high priority.
source 6/6
Indicate the source of media stream.
0 => the first stream.
1 => the second stream and etc.
weekday 6/6
Indicate which weekday is scheduled.
One bit represents one weekday.
Bit0 (LSB) => Saturday.
Bit1 => Friday.
Bit2 => Thursday.
Bit3 => Wednesday.
Bit4 => Tuesday.
Bit5 => Monday.
Bit6 => Sunday.
For example, to detect events on Friday and Sunday, set weekday
as 66.
begintime hh:mm 6/6 Begin time of weekly schedule.
