Vita Spa Portable Spa - Manual (Page 11)

P arts Check List:
(2) Side P anels
(2) Step Treads (one curved, one straight)
(1) Strip of Foam Squares
1. USING SHARP KNIFE,
carefully cut the
two locking wedges off the ends of the steps and save.
(see figure 1).
2. LAY ONE OF THE SIDE PANELS
DOWN.
Push the end of the step into the
openings on the side panel making sure the front
edge of the step is flush with the front edge of the
side panel. Repeat for second step. (See figure 2)
Note: top step is curved.
3. SECURE EACH STEP
by tapping a locking wedge
in between the side panel and the top surface of the step. (See
figure 3).
4. PEEL OFF A FOAM SQUARE
and
apply one to each of the bottom four corners to prevent
the step from slipping. (See figure 4).
P AGE 9
STEP ASSEMBLY INSTRUCTIONS (Optional Accessory)
FIGURE 1
FIGURE 2
FIGURE 3
FIGURE 4
