Page 42
K-2
Parts List
FVP-25 Encryption/DTMF Pager Unit (Option)
REF
DESCRIPTION
VALUE
V/W
TOL.
MFR'S DESIG
VXSTD P/N
VERS.
LOT SIDE LAY ADR
Printed Circuit Board
AAA27X000
FR005100F
C 1001
CHIP CAP.
0.1uF
16V
B
GRM39B104K16PT
K22124805
C 1002
CHIP CAP.
0.01uF
25V
B
GRM39B103M25PT
K22144802
C 1003
CHIP CAP.
10pF
50V
CH
GRM39CH100D50PT
K22174211
C 1004
CHIP CAP.
10pF
50V
CH
GRM39CH100D50PT
K22174211
C 1005
CHIP CAP.
0.1uF
16V
B
GRM39B104K16PT
K22124805
C 1007
CHIP CAP.
0.01uF
25V
B
GRM39B103M25PT
K22144802
C 1008
CHIP CAP.
0.1uF
16V
B
GRM39B104K16PT
K22124805
C 1009
CHIP CAP.
68pF
50V
CH
GRM39CH680J50PT
K22174231
C 1010
CHIP CAP.
390pF
50V
CH
GRM39CH391J50PT
K22174255
C 1011
CHIP CAP.
0.001uF
50V
B
GRM39B102K50PT
K22174821
C 1012
CHIP TA.CAP.
4.7uF
6.3V
TEMSVA0J475M-8R
K78080017
C 1013
CHIP CAP.
0.022uF
25V
B
GRM39B223K25PT
K22144807
C 1014
CHIP CAP.
0.1uF
16V
B
GRM39B104K16PT
K22124805
D 1001
DIODE
1SS355 TE-17
G2070470
D 1002
DIODE
1SS355 TE-17
G2070470
J 1001
CONNECTOR
AXK5S40035P
P1091012
Q 1001
IC
M64026FP-650C
G1092754
Q 1002
IC
LC73881M-TLM
G1092755
R 1001
CHIP RES.
47k
1/16W
5%
RMC1/16 473JATP
J24185473
R 1002
CHIP RES.
1M
1/16W
5%
RMC1/16 105JATP
J24185105
R 1003
CHIP RES.
22k
1/16W
5%
RMC1/16 223JATP
J24185223
R 1004
CHIP RES.
680k
1/16W
5%
RMC1/16 684JATP
J24185684
R 1006
CHIP RES.
150k
1/16W
5%
RMC1/16 154JATP
J24185154
R 1007
CHIP RES.
47k
1/16W
5%
RMC1/16 473JATP
J24185473
R 1008
CHIP RES.
22k
1/16W
5%
RMC1/16 223JATP
J24185223
X 1001
XTAL SX-1315
3.6263MHz
3.6263MHZ
H0103183
X 1002
XTAL SX-1315
4.194304MHz
4.194304MHZ
H0103184
