Vertex Standard VX-4200 - Manual (Page 19)

H-5
Parts List
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
RF Unit
PCB with Components CB1908001
Printed Circuit Board FR007990D 1-
C 1001 CHIP CAP. 27pF 50V CH GRM36CH270J50PT K22178222 1- B a3
C 1002 CERAMIC CAP. 0.001uF 100V CH GRM42-6CH102J100PT K22201202 1- A I1
C 1003 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A F3
C 1005 CHIP CAP. 12pF 500V CH CF316CH120J500AT K22271256 1- A I1
C 1006 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A C4
C 1008 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- A E3
C 1009 AL.ELECTRO.CAP. 100uF 25V ECEV1EA101UP K48140013 1- B i2
C 1010 CHIP CAP. 7pF 500V CH CF316CH070D500AT K22271252 1- B b1
C 1011 CHIP CAP. 15pF 50V CH GRM36CH150J50PT K22178216 1- B a3
C 1012 AL.ELECTRO.CAP. 10uF 25V MVA-25VC10MD55 K48140014 1- A C4
C 1013 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 1- A C2
C 1014 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A C2
C 1015 CHIP TA.CAP. 10uF 6.3V TEMSVA0J106M-8R K78080027 1- A C5
C 1016 AL.ELECTRO.CAP. 10uF 25V MVA-25VC10MD55 K48140014 1- A B4
C 1017 CHIP CAP. 0.1uF 25V B GRM40B104M25PT K22140811 1- B i3
C 1018 CHIP CAP. 47pF 50V CH GRM36CH470J50PT K22178228 1- A J4
C 1019 FILM CAP. 33pF 500V UC232H0330J-T K33279024 1- B b2
C 1020 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A C2
C 1021 CHIP CAP. 6pF 500V CH GRM42-6CH060D500PT K22271209 1- B b2
C 1022 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A C4
C 1023 FILM CAP. 33pF 500V UC232H0330J-T K33279024 1- B b2
C 1024 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- A C4
C 1026 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A C4
C 1027 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A I5
C 1028 CHIP CAP. 22pF 500V CH CF316CH220J500AT K22271259 1- B b2
C 1029 CHIP CAP. 22pF 50V CH GRM36CH220J50PT K22178220 1- A C4
C 1030 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A I5
C 1031 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A B3
C 1032 CHIP CAP. 22pF 50V CH GRM36CH220J50PT K22178220 1- A C5
C 1033 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B j4
C 1034 CHIP CAP. 2pF 50V CK GRM36CK020C50PT K22178204 1- A I5
C 1035 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A G3
C 1036 CHIP TA.CAP. 10uF 10V TEMSVA1A106M-8R K78100028 1- A G3
C 1037 CHIP CAP. 18pF 500V CH CF316CH180J500AT K22271258 1- B b3
C 1038 CHIP CAP. 3pF 50V CJ GRM36CJ030C50PT K22178205 1- A I5
C 1040 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A G3
C 1042 CHIP TA.CAP. 10uF 6.3V TEMSVA0J106M-8R K78080027 1- A D6
C 1043 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A I5
C 1044 CHIP CAP. 18pF 500V CH CF316CH180J500AT K22271258 1- B b3
C 1045 CHIP CAP. 3pF 50V CJ GRM36CJ030C50PT K22178205 1- A I5
C 1046 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A G3
C 1048 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B b3
C 1049 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A C6
C 1050 CHIP CAP. 0.0018uF 50V B GRM36B182K50PT K22178812 1- A C6
C 1052 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B c3
C 1053 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B c3
C 1054 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A H4
C 1055 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A G4
C 1056 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B g6
C 1057 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A H4
C 1058 CHIP CAP. 47pF 50V CH GRM36CH470J50PT K22178228 1- A H4
C 1059 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A H3
C 1060 CERAMIC CAP. 0.001uF 100V CH GRM42-6CH102J100PT K22201202 1- A G3
C 1062 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A H3
C 1064 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B c3
C 1065 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B c4
C 1066 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B g6
C 1068 CHIP TA.CAP. 4.7uF 6.3V TEMSVA0J475M-8R K78080017 1- B g5
C 1069 CHIP TA.CAP. 4.7uF 6.3V TEMSVA0J475M-8R K78080017 1- B g6
C 1070 CHIP CAP. 0.0022uF 50V B GRM36B222K50PT K22178813 1- B f6
C 1071 CHIP TA.CAP. 4.7uF 6.3V TEMSVA0J475M-8R K78080017 1- B g5
C 1072 CHIP CAP. 1uF 10V B GRM40B105K10PT(0.85) K22100803 1- B h4
C 1073 CHIP CAP. 22pF 50V CH GRM36CH220J50PT K22178220 1- A C5
C 1074 CHIP TA.CAP. 4.7uF 6.3V TEMSVA0J475M-8R K78080017 1- B g6
C 1075 CHIP CAP. 150pF 50V CH GRM36CH151J50PT K22178240 1- B f7
C 1076 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B h4
C 1077 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B g6
C 1079 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B c3
C 1080 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A H3
C 1081 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A H3
C 1082 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B g6
