www.vtechphones.com 6
Installation
Wall mounting bracket installation (optional)
Your telephone base comes with the wall mounting/desktop bracket installed, ready for desktop use
If you prefer to mount your telephone on the wall (optional), it is designed to mount on a standard
telephone wall plate For wall mounting, follow these instructions:
Desk/table bracket installation
To place your telephone base on a desk or table, insert the
wall mounting/desktop bracket
Insert the lower portion tabs of the bracket into the upper
grooves of the telephone base
• Snap the upper portion tabs of the bracket into place
To remove the bracket, press both upper portion tabs
firmly inward and pull the bracket upward until it is
released from the grooves
•
•
• First, insert the lower portion tabs of the wall mounting/desktop bracket into the lower grooves in
the telephone base, then snap the upper portion tabs of the bracket into place
• Mount the telephone base on the wall by positioning it so the mounting studs will fit into the holes
on the telephone base and wall mounting/desktop bracket Slide the telephone base down on the
mounting studs until it locks into place
To remove the bracket, press both upper portion tabs firmly inward and pull the bracket downward
until it release from the grooves
•
upper portion tab
upper grooves
lower portion tab
lower groove
