VENTILATION
Built-In Custom Ventilator Systems
P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
Ventilator Kits
• See Installation Requirements table for recommendations for each hood model
• One ventilator, one duct run for any size hood/ventilator
• A 1,200 CFM interior or 1,500 CFM exterior (if applicable) ventilator should be used over ranges/rangetops with gas grill
• Must use Viking ventilator kits with Viking hoods; use of non-Viking kits voids product warranty
Compliance Information
WARRANTY SUMMARY*
• Three-year full warranty—complete product (Professional and Designer)
• Five-year limited warranty—all ventilator motors (Professional and Designer)
• Ninety-day limited warranty—cosmetic parts such as glass, painted, and decorative items (Professional and Designer)
*Must use Viking ventilator kits with Viking hoods; use of non-Viking kits voids product warranty. For complete warranty see Use & Care Guide.
Warranty valid on Viking products shipped within the United States and Canada.
✪ Installation Notes & Accessories
Kit model Description Hood models Approx. ship wt. lbs. (kg)
VINV300 300 CFM interior-power VBCV3038/3638 & DBCV3082/3682 27 (12.2)
VINV600 600 CFM interior-power VBCV3038/3638/4238 & VICV3698/4298 27 (12.2)
DBCV3082/3682/4282 & DICV3632/4232
VINV1200 1,200 CFM interior-power VBCV3038/3638/4238/4838/5438/6038/6638 & 43 (19.4)
VICV3698/5498/6698 & DBCV4882 & DICV5432
DEV900 900 CFM exterior-power DBCV3082/3682/4282 & DICV3632/4232 39 (17.6)
VBCV3038/3638/4238 & VICV3698/4298
DEV1200 1,200 CFM exterior-power DBCV3082/3682/4282/4882 & DICV3632/4232/5432 53 (23.9)
VBCV4838/5438/6038/6638 & VICV3698/4298/5498/6698
DEV1500 1,500 CFM exterior-power DBCV4882 & DICV4232/5432 53 (23.9)
VBCV4838/5438/6038/6638 & VICV4298/5498/6698
DIL900 900 CFM in-line power DBCV3082-DBCV4282 & DICV3632/4232 20 (9.1)
VBCV3038/3638/4238 & VICV3698/4298
DIL1200 1,200 CFM in-line power DBCV3082-DBCV4882 & DICV3632-DICV5432 25 (11.3)
VBCV3038-VBCV6638 & VICV3698-VICV6698
R E V I S E D 5 / 2 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
