Set Temperature Activation Threshold (TWRFS-I models only)

The freeze sensor temperature activation threshold is adjustable from 2°C to 7°C ( 35°F to 45°F).
When the air temperature reaches the threshold setting, the freeze sensor activates the receiver,
and the

Freeze Status indicator will turn on. The sensor system will return to the Monitor mode

when the outside air temperature rises above the sensor threshold temperature.

Select Centigrade or Fahrenheit Temperature Scale
1. Press the

Setup button to display the current temperature scale

(°C or °F) and the

Setup icon will begin flashing to indicate the

selected feature can be adjusted. See Figure 16.

2. To select the alternate temperature scale, press the

Advance button.

Select Temperature Threshold
1. Press the

Setup button to display

Temperature icon. The display

will indicate the current temperature threshold setting and the

Setup

icon will begin flashing to indicate the selected feature can be adjusted.
See Figure 17.

2. Press the

Advance button to set the sensor threshold temperature.

Congratulations! Your Wireless Rain Sensor system installation is complete. To take advantage
of the unique Water Conservation feature, review the information on the next page to select the
conservation level that best suits your landscape irrigation needs.

Figure 16

Figure 17
