5. Install hinge on opposite
side, bottom of cabinet (see
Figure 18). Replace nut on
back side where installed.
Align hinge outer edge with
cabinet before tightening
screws.
3. Lift the door off the bottom
hinge.
4. Remove bottom hinge from
cabinet (2 screws) (see
Figure 16). Remove screws
on opposite side of cabinet
(see Figure 17). Note that
there may be a nut behind
one or both screws on either
side.
15
UL210
Figure 17
UL212
Figure 18
UL211
Figure 16
6. Relocate plastic spacer/
bushing on bottom of door to
opposite side, and place
door on bottom hinge pin
(see Figure 19). Clean out
bushing hole in door bottom
with a screwdriver if needed.
7. Remove plastic hole plug
from door handle and relo-
cate on opposite side.
UL113
BUSHING
Figure 19
