Direct wall mounting
If you don't have a standard wall plate, you can mount your phone
directly to the wall. Before doing this,
consider the following:
•
Avoid electrical cables, pipes, or other items behind the mounting
location that could cause a hazard when inserting screws into the wall.
•
Try to mount your phone within 1.5m of a working phone jack to
avoid excessive cord lengths.
•
Make sure the wall material is capable of supporting the weight of
the main base and handset.
•
Use #10 screws (minimum length of 35mm) with anchoring
devices suitable for the wall material where the main base will be
placed.
1) Insert two mounting screws into the wall, (with their appropriate anchoring device), 100mm apart.
Allow about 3mm between the wall and screw heads for mounting the phone.
2) Refer to steps 1 through 7 on page 9 to mount the telephone.
Insert the beltclip into the holes on each side of the handset. Press down until it clicks.
Pull both sides of the beltclip to release the tabs from the holes.
Installing the Beltclip
To attach the beltclip
To remove the beltclip
[10]
INST
ALLING
THE
PHONE
3mm
100mm
35mm
