Series 600 POS Keyboard
58
OPOS PROGRAMMING
The OPOS keys are defined in Table 7 below. All OPOS keys have the prefix of E0h/48h added
to them.
Example for OPOS key #32: The output in scan set 2 is E0 48 33 F0 33. All data is sent on the
make of the key.
Note: See Appendix D for keyboard key number format and scan code cross reference.
Table 7 OPOS Key Definitions
OPOS
Key No. Output OPOS
Key No. Output OPOS
Key No. Output
01 01 02 02 03 03
04 04 05 05 06 06
07 07 08 08 09 09
10 10 11 11 12 12
13 13 14 15 15 16
16 17 17 18 18 19
19 20 20 21 21 22
22 23 23 24 24 25
25 26 26 27 27 28
28 29 29 31 30 32
31 33 32 34 33 35
34 36 35 37 36 38
37 39 38 40 39 41
40 42 41 45 42 46
43 47 44 48 45 49
46 50 47 51 48 52
49 53 50 54
