Uniden UH-042XR User Manual

Page 27

background image

1. Speaker Jack

2. Microphone Jack

3. On/Off Volume

4. LCD Display

5. Up Button

6. Down Button

7. Microphone

8. Speaker

9. Scan and VOX Button

10. Open/Group Scan and

CTCSS Button

11. Memory/BCL Button

12. Duplex and Key Lock

On/Off Button

13. PTT (Push-to-talk) Button

14. Monitor Switch

15. Belt Clip

A. Transmit

B. Channel Numbers

C. Key Lock

D. Memory

E. Battery Level Indicator

F. Duplex Transmit

G. Scanning

H. Group Scanning

I. Receiving

J.

CTCSS Tone and VOX Levels

K. Busy Channel Lock

L. VOX
