Using the Alkaline Battery Case
When needed, you can use the battery case with AA Alkaline bat-
teries (not included) instead of the rechargeable battery pack.
3 Replace the battery case cover as follows
until it clicks into place.
Attaching the Beltclip
1 Hold the beltclip in the direction as
illustrated.
2 Apply it to the hanger piece on the back of
the radio. Then slide it up.
3 When you hear a click, the beltclip is firmly
attached.
4 To take the beltclip off the radio, turn it
upside down and slide it up.
9
AA
AA
AA
AA AA
AA
To install the batteries:
1 Remove the battery case cover by pulling
the 2 halves apart applying your fingers to
the projections.
2 Install 6 AA Alkaline batteries
(not included) into the battery case.
Be certain to follow the + and - symbols
in the compartment.
