7
If you are using an
optional headset, you
must still use the handset
keypad for phone
operations.
!
headset
jack
HEADSET INSTALLATION
ADJUSTING THE RINGER AND EARPIECE VOLUME
Ringer tone and volume
The phone has four ringer tone and volume
combinations.
In the standby mode, press or on the
handset repeatedly.
The display shows the setting.
RINGER A HIGH
Earpiece volume
Pressing or during a call will change the
earpiece volume of the handset. The telephone will
keep this setting for all calls and display the setting
for each call.
Loud High Mid Low
TALK LOUD 1
Your phone may be used with an optional
headset.
To use this feature, simply plug the headset into
the headset jack.
To attach the
beltclip To remove the
beltclip
INSTALLING THE BELTCLIP
l
Gently pull
one side of
the beltclip to
release. l
Press the beltclip
against the rear of the
handset until it clicks
into place.
options redial/p select/ channel delete
1 2 3
4 5
7
6
8 9
* 0 # tone
pqrs
g h i
abc def
mno j k l
wxy t u v
oper
talk cid
memory flash
vol
