Ultra Products ULT31312 - Manual

600 Watt ATX
Continuous Power Supply
Black
600 Watt ATX Power Supply
Unit
Part #: ULT31314 UPC#: 022769313146
Weight: 3 lbs. Dimensions: 8x4x7"
Master Pack
Qty: 6 Weight: 29 lbs.
Dimensions: 20.9x10x8.66"
Titanium
600 Watt ATX Power Supply
Unit
Part #: ULT31638 UPC#: 022769316383
Weight: 3 lbs. Dimensions: 8x4x7"
Master Pack
Qty: 6 Weight: 29 lbs.
Dimensions: 20.9x10x8.66"
MS Blue
600 Watt ATX Power Supply
Unit
Part #: ULT31312 UPC#: 022769313122
Weight: 3 lbs. Dimensions: 8x4x7"
Master Pack
Qty: 6 Weight: 29 lbs.
Dimensions: 20.9x10x8.66"
This power supply runs at full wattage
continuously. Unlike older power
supply technology that delivers variable
wattage output, Ultra power supplies run at peak power 24/7 - with
no valleys! Superior power all the time.
Features
· High-Gloss Mirror Finish
· Dual 80mm Fans
· Low Acoustic Noise
· Supports Pentium 4 and AMD CPUs
· Meets ATX Version 2.03 and
ATX 12V Version 1.2 Specifications
· MTBF > 100,000 Hours at Full Load,
· 110VAC and 25˚C Ambient Condition
· Serial ATA Drive Connectors (2)
· 20-Pin to 24-Pin Motherboard
Power Adapter
DUAL 80mm
Fans
1-800-830-0051
www.ultraproducts.com
600 WATT
EFFICIENCY
70% Typical at Full Load and Nominal Input Voltage
INPUT
· AC Input Voltage:
· AC Input Frequency:
· AC Input Current:
Max Output
Current
Max Combined
Wattage
232 W 348 W 7.2 W 3 W 10 W
580 W 20 W
+3.3VDC +5VDC +12VDC -12VDC -5VDC +5VSB
28A 28A 29A 0.6A 0.6A 2.0A
600 W
OUTPUT
TOTAL OUTPUT POWER
600W (Full Load, Nominal Input Voltage).
115V/230V
50-60Hz
10.0A (RMS) for 115VAC input
6.0A (RMS) for 230VAC input
Power Protections:
Short Circuit, In-rush Current, Thermal Overload,
Over-Temperature, Over-Voltage, Over-Current,
Under-Voltage
Featuring
Ultra Violet
Clear Sides
