Ultra Products X2 750W - Manual

X2 750W Power Supplies
Extreme Edition
Features
· SLI™ Certified
· 120mm Fan
· Thermostatically controlled
fans for low acoustic noise.
· Dual Rail Technology
· FlexForce Cabling Technology
· Meets ATX v2.2, v1.3 and
ATX 12V v2.02 Specifications
· Power Protections:
Short Circuit, In-rush Current,
Thermal Overload, Over-Temperature,
Over-Voltage,Over-Current, Under-Voltage
1-800-830-0051
www.ultraproducts.com
X2 Extreme Edition PSU - Patented Technology
If you’re familiar with the 1st Generation X-Connect you know that it’s
the world’s first completely modular design. That means you only have to connect
the cables you need. This leaves your system’s airflow unimpeded by clunky, chunky
air stifling cables. The end result? Airflow that cools and protects your precious
components. This next generation, Extreme Edition, born-to-be-modded power
supply goes several steps beyond its award-winning predecessors.
The Ultra 750W X2-Extreme Edition features FlexForce technology, which delivers
easy cable routing while remaining hidden within your case. FlexForce’s special
design promotes 30% better airflow than standard cables. This results in a quantum
leap in performance. Specially developed for extreme gaming rigs!
This 750 watt X2-Extreme Edition features Dual Rail Technology. The X2’s critical 12V
power are divided into two separate rails. This distributes cleaner power to your
CPU, offering better stability and greater overclocking potential. You’ll get
phenomenal system performance with the this 750 watt X2-Extreme Edition!
Featuring
750 Watt ATX Power Supply - Titanium w/ UV Side
Part #: ULT40121
UPC#: 022769401218
Weight: 6 lbs. Dimensions: 8x4x7"
Max Output
Current
Max Combined
Wa ttage
160 W 600 W 9.6 W 12.5 W
728 W 22 W
+5V 3.3V +12VDC1 +12VDC2 -12VDC +5VSB
28A 24A 25A 25A 0.8A 2.5A
750 W
OUTPUT 750Watt
Total Output Power:
750W (Full Load, Nominal Input Voltage)
Maximum 72% Efficiency
Input:
AC Input Voltage: 115V/230V
AC Input Frequency: 50-60Hz
AC Input Currents:
· 11.5A (RMS) for 115VAC input
· 6.5A (RMS) for 230VAC input
750 Watt ATX Power Supply - Titanium
Part #: ULT40122
UPC#: 022769401225
Weight: 6 lbs. Dimensions: 8x4x7"
120mm
Cooling Fan
3V Rail
5V Rail
12V Rail 1
12V Rail 2
OUTPUT
1
15V
AC / 230V
AC INPUT
What is Dual Rail Technology?
- Better Power Distibution - Dual Rail
Technology distributes power to
components that require it the most.
- Dedicated CPU Rail - Dedicated 12V
Rail for the 2x2 Motherboard Connector
- More power where you need it..
.
Modular Cabling
Technology
U V -R e a d y
C a b l e s !
U V -R e a d y
C a b l e s !
INCLUDES
Patented Technology
