DO NOT use an
outlet controlled by a
wall switch.
Standard wall plate mounting
1 Snap the wall mount adapter into
the notches on the base.
This phone can be mounted on any standard telephone wall plate.
2. Plug the telephone line cord to the
TEL LINE 1/2 jack and the AC
adapter to the DC IN 10V jack.
3. Plug the telephone line cord into the
telephone outlet.
4. Wrap the AC adapter cord inside the
molded wiring channel. Then wrap
the cord around the strain relief notch.
5. Plug the AC adapter into a standard
120V AC wall outlet.
6. Raise the antenna to a vertical position.
7. Align the mounting slots on the base
with the mounting posts on the wall.
Push in and down until the phone is
firmly seated.
WALL INSTALLATION
6
Place the power cord so
that it does not create a
trip hazard or where it
could become chafed
and create a fire or
electrical hazard.
