User’s Manual
LEVELING THE UNIT
It is important that these units, primarily the ice maker assembly and
75 BEV are level. All 75 and 15 Series units are equipped with
adjustable feet for leveling and height adjustment (Figure 3). All other
units have rubber feet.
To level units with adjustable feet:
1. Adjust all four leveling feet evenly so that the top of the cabinet is
at the desired installation height and level.
2. Using a level of at least two feet in length, measure the level of the
floor where the unit is to be installed. Measure back-to-front and
side-to-side and note the measurements.
3. With the unit on a level surface, adjust the feet, as appropriate, to
compensate for the floor level measurements noted in Step 2.
