Configuring I/O Cabinets
4–2 7017 6300–005
Table 4–1. Cabinet Styles
Status Style Description
Orderable BRM36-O First or only open-front style cabinet in a row. 36U high.
BRM36-O2 Second and additional open-front style cabinets in a row. 36U high.
Migration RM36-1 First or only louvered-door style cabinet in a row. 36U high.
RM36-2 Second and additional louvered-door style cabinets in a row. 36U high.
Table 4–2. Configuration Guidelines for I/O Cabinets
Rule Description
1 Optional cabinets higher than 19U require a cable manager.
2 The following UIO style I/O bases can be migrated to the system. Refer to the documentation
for the system from which the units are being migrated for configuration information.
General guidelines are as follows:
•
RM9-IO1 - First I/O base in cabinet. Without fascia.
•
RM9-IO2 - Second and subsequent I/O bases in cabinet. Without fascia.
•
RM9-IO3 - Can be migrated with the installation of upgrade style RM934-CNV. With
fascia.
•
RM9-IO4 - First I/O base in style cabinet. With fascia.
•
RM9-IO5 - Second and subsequent I/O bases in cabinet. With fascia.
Maximum capacities are as follows:
•
I/O bases per UC36 cabinet = 4 maximum
•
I/O bases per UC19 cabinet = 2 maximum
•
Cards per I/O base = 18 maximum
