Configuring Optional and Recommended UPS
7017 6300–005 6–51
Table 6–35. UPS Options
Component
Style Name Interconnect Configuration and
Cable Part No.
Industry-Compatible UPS Systems Notes
UPS915-WC6 15-Pin Male “D” to 9-Pin Male
(7015 5411-001) Deltec 90S 1, 2, 7
9-Pin Male “D” to 9-Pin Male
(7015 6260-003) Deltec 6000 1, 2, 7
Expansion Box Options
UPS111-EXP Expansion Box for Variable Length
Cable Any of the above 3, 7, 8
UPS5-EXP Expansion Box with Fixed-Length
(5-Foot) Interconnect Cable Any of the above located in the same cabinet
or adjacent (latched together) cabinet 4, 7
UPS1000-INT UPS/SCJ Interconnect Box None of the above. NUL (Japan) use only. 5, 7
UPS Interconnect Cables (One to One Cable)
CBL5-UPS UPS Cable (5 ft), 7015 5403-000
9-Pin Female to 9-Pin Female Any except UPS5-EXP
(contains 7015 5403-000) 6, 9
CBL10-UPS UPS Cable (10 ft), 7015 5403-001
9-Pin Female to 9-Pin Female Any except UPS5-EXP
(contains 7015 5403-000) 6
CBL15-UPS UPS Cable (15 ft), 7015 5403-005
9-Pin Female to 9-Pin Female Any except UPS5-EXP
(contains 7015 5403-000) 6
CBL25-UPS UPS Cable (25 ft), 7015 5403-002
9-Pin Female to 9-Pin Female Any except UPS5-EXP
(contains 7015 5403-000) 6
CBL50-UPS UPS Cable (50 ft), 7015 5403-003
9-Pin Female to 9-Pin Female Any except UPS5-EXP
(contains 7015 5403-000) 6
CBL100-UPS UPS Cable (100 ft), 7015 5403-004
9-Pin Female to 9-Pin Female Any except UPS5-EXP
(contains 7015 5403-000) 6
Notes:
1. Includes interconnect box (7016 0619-001), NT jumper cable assembly (7015 7789-000), and
configuration-specific adapter cable assembly.
2. One UPS interconnect cable (CBLxx-UPS) is required per UPS or add-on style . Must be ordered
separately.
3. Includes interconnect box (7016 0619-001) and NT jumper cable assembly (7015 7789-000) .
Compatible with any of the interconnect configuration styles.
4. Includes interconnect box (7016 0619-001), NT jumper cable assembly (7015 7789-000), and 5-foot
UPS cable (CBL5-UPS).
5. Restricted to NUL (Japan) use . Includes interconnect box only.
6. See Table 6-36 to select proper cable length when going between SCP’s and servers.
7. The available UPS styles and expansion box options listed contain a NT jumper cable (7015 7789-
000) that connects to the NT server only (not used for SCP console). For additional NT server, order
UPS111-EXP.
8. Order for additional NT server.
9. Must be ordered separately when central site is used for dual SCP consoles.
The SCP jumper cable (7015 7789-001) and distribution box (7016 0619-001) used for the SCP
console is provided with the system under the primary and redundant console styles.
