12
Filtering
• There is a maximum of 100 filters allowed for each category (User IPs, User MACs, and
Administrator MACs).
• To enable IP filtering for User Stations, Click to put a check mark in the IP and/or MAC
Filter enable checkbox.
• To add a filter, Click Add. Dialog boxes similar to the ones below appear (the top example
is for IP address filters; the bottom is for MAC address filters):
• Specify the filter address in the dialog box, then Click OK.
• Each IP filter can consist of a single address, or a range of addresses. For IP filtering, a
second dialog box similar to the one below appears:
To filter a single IP address, key in the same address as the start IP. To filter a continuous range
of addresses, key in the end number of the range.
• Click OK when done.
• To delete a filter, select it and Click Remove. To modify a filter, select it and Click Edit. The
Edit dialog box is similar to the Add dialog box. When it comes up, simply delete the old
address and replace it with the new one.
• User Station filtered items can be specified as included or excluded by highlighting the item
and clicking the include or exclude radio button.
– If the include button is checked, all the addresses within the filter range are allowed access
to the B014-000; all other addresses are denied access.
– If the exclude button is checked, all the addresses within the filter range are denied access
to the B014-000; all other addresses are allowed access.
• The Administrator station filter dialog boxes are similar to the MAC filter dialog boxes for
user stations.
Administration
