6. Specifications
Supported resolutions: HDMI - 480i/480p, 576i/576p, 720p@50/60Hz,
1.
1080i@50/60Hz, 1080p@50/60Hz
Transmitter Input: 1 HDMI female connector
2.
Transmitter Output: 1 x CAT-6 input for Video, 1 x CAT6 input for DDC
3.
Receiver Input: 1 x CAT-6 input for Video, 1 x CAT6 input for DDC
4.
Receiver Output: 1 HDMI female port
5.
Power: Input 5V/2.6A DC Power Supply (US/EU standards, CE/FCC/UL
6.
certified).
7.
Operating Temperature: 32°F (0°C) ~ 104°F (40°C)1
8.
9.
Weight: 6.8oz
10.
7. Connection and Installation
8. Connection and Installation with HXC6R
I
M
D
H
I
M
D
H
HDMI LCD TV
Transmitter
Receiver
DVD PLAYER
HDMI
Cable
DDC
VIDEO
HDMI
Cable
I
M
D
H
I
M
D
H
CAT6
I
M
D
H
I
M
D
H
HDMI LCD TV
Transmitter
Receiver
DVD PLAYER
HDMI
Cable
DDC
VIDEO
HDMI
Cable
I M
D
H
I
M
D
H
CAT6
HXC6R
Repeater
DDC
VIDEO
CAT6
5
