4. Transmitter Operation Controls and Functions
4.1 Front Panel
HDMI INPUT: Connect the HDMI input to the HDMI of your source equipment
such as a DVD player or set-top-box.
Power: Plug the 5VDC power supply into the unit and connect the adaptor to
AC wall outlet.
1
2
4.2 Rear Panel
DCC OUTPUT: Connect the DDC output to the DDC input of the receiver unit
using CAT5E or CAT6 cable.
Video OUTPUT: Connect the VIDEO output to the VIDEO input of the receiver
unit using CAT5E or CAT6 cable.
1
2
4 3
1 2
VIDEO DDC
CAT6 OUTPUT
DC 5V
POWER
HDMI INPUT
1 2
