Ver.1.0
15.
Electronic shutter
(ELC)
ON/OFF selectable
Corrective range under ON setting : 0dB~60dB
Under OFF mode : Refer to table 5 Shutter Speed Setting
16. White balance
AUTO/HOLD one-push selectable
Corrective range under AUTO mode : 2800K~6500 K
17. Power source DC12V 10% (Ripple voltage : 20mV(p-p))
18. Power consumption Approximately 230mA(DC12V)
19. Ambient condition
Temperature:0 40
Humidity: 30 85% (No condensation)
20.
External dimension
Refer to Ex-view of CS5260BD/BDP
21. Lens mount C mount
22. Weight Approx. 95g
23. Connector for power supply/image
Compatible connector
HR10A-10P-12S (Manufactured by HIROSE DENKI)
Pin number
Signal name
1 GND
2 +12V
3 GND
4 VIDEO
OUT
5 GND
6 SI
(Adjustment signal)
7 N.C.
8 C.OUT
9 SO(Adjustment
signal)
10 Y.OUT
11 +12V
12 GND
