Ver.1.0
1. Product descriptions
The CS5260BD/BDP is a one-piece type (*) CCD color camera with a ultra-compact & light-weight body.
[*One-piece type : One integrated body made up of the camera head & the camera control unit]
2. Features
(1) The camera is driven by DC12V.
(2) The ultra-compact & light-weight body is best suited for observation and other applications.
(3) The built-in automatic white-balancing function allows the user to obtain optimal white-balance just with a push on the
button.
3. Configuration
(1) The camera body ······························· 1
(2) Accessories
Instruction manual (Japanese)········· 1
Instruction manual (English) ··········· 1
4. Specifications
Model
CS5260BD
CS5260BDP
1. TV
system
NTSC
PAL
2.
Image sensor
Interline CCD
Total
pixels
811(H)
508(V) 795(H)
596(V)
Active
pixels
768(H)
494(V) 752(H)
582(V)
6.45(H)
4.84(V)mm 6.47(H)
4.84(V)mm
Scanning
area
(Equivalent to 1/2 inch optical image size)
Pixel
size
8.4
m(H)
9.8
m(V) 8.6
m(H)
8.3
m(V)
Color filter
Corrective mosaic filter (Ye, Cy, Mg, G)
CCD integration
Field integration (Field-electrical-charge-storage)
3.
Scanning lines
525 lines
625 lines
4.
Scanning system
2:1 interlace
5. Sync
system
Internal
6.
Scanning frequency
15.734kHz(H), 59.94Hz(V)
15.625kHz(H), 50Hz(V)
7. Aspect
ratio
4:3
8.
Sensitivity
1000 lx (F8, 3000K)
9.
Minimum subject illumination
4 lx (F1.4, AGC ON, Output level: Approx. 50%)
10. Video
output
VIDEO VBS :1.0 V(p-p)/75
terminal, Positive
Y/C : 1.0 V(p-p)/75
terminal, Positive
CHROMA: 0.286 V(p-p)/75
terminal
11. Resolution
470 TV lines(H)
350 TV lines(V)
470 TV lines(H)
420 TV lines(V)
12. S/N
ratio
46dB(p-p)/rms
13. Correction
0.45
(Fixed)
14.
Gain
(AGC)
ON/OFF selectable
Corrective range under ON mode : 6dB~0dB
Corrective range under OFF mode : Selectable among
18dB, 12dB, 6dB, 0dB
1
