Tiger Dear Diary SnapShot Organizer 71-555 - Manual (Page 3)

3
Replacing the Back-up Battery
Note: This battery was installed at the factory and, with normal use,
should not need changing for 24 months after you begin using your
Dear Diary SnapShot Organizer.
WARNING: DO NOT REMOVE THE MAIN BATTERIES
AND THE BACK UP BATTERY AT THE SAME TIME.
IF YOU DO, ALL YOUR DATA WILL BE LOST.
1. Make sure the organizer is
turned off. Using a Phillips
®
screwdriver, remove the
screw from the back-up
battery compartment door on
the back of the unit.
2. Remove the battery compartment door.
3. Remove the old battery
using a thin, pointed,
non-metallic object to lift it.
4. Wipe the surface of the new
CR2032 button cell battery
with a soft, dry cloth. Insert
it so that the “+” side is
facing you.
5. Replace battery compartment door and screw.
