Model 3000TA
Quickstart Guide
Teledyne Analytical Instruments
5
•
Analog Output Connection: Terminals for current and voltage analog output
signals.
•
Digital Input Terminals: Terminals for connecting digital input signals.
•
Alarm Connections: 2 concentration alarms and 1 system alarm.
•
Calibration Contact : To notify external equipment that instrument is being
calibrated and readings are not monitoring sample.
•
Range ID Contacts: Four separate, dedicated, range relay contacts. Low, Medium,
High, Cal.
•
Remote Span/Zero: Digital inputs for externally controlling calibration.
•
Network I/O: Serial digital communications for local network access.
