Quickstart Guide Trace Oxygen Analyzer
Teledyne Analytical Instruments 16
Span Calibration
Make sure an appropriate span gas is connected to the sample port.
Auto Mode Spanning:
•
Press Span to enter the span function.
•
Use the arrow keys to toggle between AUTO and MAN span settling. Stop when AUTO
appears, blinking on the display.
Span: Settling: AUTO
For Next
•
Press Enter.
Calib. Holding time
Cal hold: 5 min
•
Press Enter to move to the next screen.
Span Val: 000008.00
Span Mod #
•
Use the ▲▼ arrow keys to enter the oxygen-concentration mode. The ◄► arrows
choose the digit, and the ▲▼ arrows choose the value of the digit. When you have
finished typing in the concentration of the span gas you are using, press Enter to
begin the span calibration.
#### ppm Span
Slope=#### ppm/s
The instrument automatically returns to the Analyze mode at the conclusion of the auto span
cycle..
Manual Mode Spanning:
•
Press Span to start the Span function.
Span: Settling:MAN
For Next
•
Use the ▲▼ keys to toggle between AUTO and MAN span settling. Stop when MAN
appears, blinking, on the display. Press Enter to move to the next screen.
