T H E I N F O M O D E
14
Overview of the Info Mode
The
INFO MODE
serves four main purposes:
1. To display general oven information.
2. To provide access to
TEST MODE
and additional
diagnostic tools for service technicians.
3. To turn oven options and features on/off.
4. To update oven settings.
To access the
INFO MODE
, simply press the Info key
when the oven is either off or cooling down. To toggle
between the Info screen 1 and 2, press the Up or
Down key.
Screen 1 of the
INFO MODE
(Figure 20) includes:
- Oven serial number
- Oven software version
- Menu part number and revision
- Last temperature selected to cook
- Current electrical compartment temperature
- Counters (scroll by pressing adjacent softkey)
- Operating voltage (USA models only)
- Access to the fault log
- Access to service phone numbers
Screen 2 of the
INFO MODE
(Figure 21) includes:
- Access to
TEST MODE
- Access to the “Options” screen
- Language (set by pressing adjacent softkey - not
available on all models)
- Access to date/time settings
- Sound (press adjacent soft key to increase/decrease
the volume)
- Access to the “Load Menu” screen
Viewing Cook Counter/Time Logs
From the
INFO MODE
(Figure 20), press the R1 soft key:
- Once to display the cook counter.
- Twice to display total cook time.
- Three times to display total magnetron time.
- Four times to display total “oven on” time.
MENU P/N AND REV
INFO 1
SOFTWARE VERSION
SP: 500F
EC TEMP: 84F
SERIAL NUMBER
FAULT LOGS
VAC = 240
SERVICE NUMBERS
COUNTS SCROLL
SET LANGUAGE
INFO 2
SET OPTIONS
SET DATE/TIME
TEST MODE
LOAD MENU
SOUND = = = = = = 7
Figure 20: Info Mode Screen 1
Figure 21: Info Mode Screen 2
F6: EC OT
F8: HX RISE LOW
F1: BLOWER
F2: LOW TEMP
F3: MAG C LOW
F4: MONITOR
F5: MAG OT
FAULT LOG
8
0
0
0
0
F7: RTD OPEN
0
0
0
Figure 22: Fault Log
