Tyan Computer THUNDER N3600QX User Manual
Page 13
Jumper Placement
J3: Front Panel Connector (14Pin x 2)
Signal
Pin
Pin
Signal
HD LED+
1 2 HD LED-
Reset Button+
3 4 Reset Button-
PW LED+
5 6 PW LED-
Fault LED+
7 8 Fault LED-
SM BUS DATA
9 10
SM BUS CLK
NMI Button
11
12
NMI Button-
5VSB
13
14
INTRUDER#
PWR Button+
15
16
PWR Button-
LAN2 LED+
17
18
LAN2 LED-
LAN1 LED+
19
20
LAN1 LED-
Reserve
21
22
Reserve
ID LED+
23
24
ID LED-
ID LED Button+
25
26
ID LED Button-
KEY PIN
27
28
NC
J12
J3
J5
J18
J29
13
