TRENDnet TW100 S4W1CA User Manual
Page 19
33
2-5-4 DMZ (Demilitarized Zone)
If a local client PC cannot run an Internet application properly from
behind the NAT firewall, open the client up to unrestricted two-way
Internet access by defining a PC as a virtual DMZ Host.
2-6 Routing
2-6-1 Static Routing
Static routing determines the path that data follows over your network
before and after it passes through your router. You can use static routing
to allow different IP domain users to access the Internet through the
device
34
TECHNICAL SPECIFICATIONS
General
Standards
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
ANSI/IEEE 802.3 Auto-negotiation
Protocol CSMA/CD
Data Transfer
Rate
Ethernet: 10Mbps (half duplex), 20Mbps (full-duplex)
Fast Ethernet: 100Mbps (half duplex), 200Mbps (full- duplex)
Topology Star
Network
Cables
10BASET: 2-pair UTP Cat. 3,4,5 (100 m), EIA/TIA- 568 100-
ohm STP (100 m)
100BASE-TX: 2-pair UTP Cat. 5 (100 m), EIA/TIA-568 100-ohm
STP (100 m)
Number of
Ports
LAN: 4 x 10/100Mbps Auto-MDIX Fast Ethernet port
WAN: 1 x 10/100Mbps Auto-MDIX Fast Ethernet port
Physical and Environmental
DC inputs
Switching Power 5V 800mA or Linear Power 9V 800mA
Power
Consumption
3W (Max)
Temperature
Operating: 0
° ~ 40° C, Storage: -10° ~ 70° C
Humidity
Operating: 10% ~ 90%, Storage: 5% ~ 90%
Dimensions
154 x 110 x 33mm (6 x 4.3 x 1.3 inches)
EMI: FCC,
CE
