Input selection and AV connections

16

Defining the INPUT and OUTPUT sockets so that the television recognises connected equipment. See page 5
for a clear view of the back connection recommendations.

Select Ext2 output.

Use Sor Rto change the Ext2 output option to:

Monitor = The picture on screen.

TV = The last television programme selection.

EXT1 = The picture from equipment connected to
Scart 1.

EXT3 = The picture from equipment connected to
the front input sockets.

This specifies the type of signal going into Scart 2 (EXT2)
on the back of the TV. Please refer to the manufacturers
instructions for the connected equipment.

From the Feature menu select EXT2 input
and with

S or R select either Video or

S-VIDEO as the required input.

This enables selection of the source to output from
Scart 2. For example, to record transmissions in stereo
from a stereo decoder – connect a stereo decoder to
Scart 1 and stereo VCR to Scart 2, then select EXT1 as
the Ext2 output. The signal received through Scart 1 will
output directly through Scart 2.

Most VCRs and decoders send a signal through the Scart
lead to switch the TV to the correct Input socket.
Alternatively press the external source selection button

B

until the picture from connected equipment is shown.

An S e.g. EXT2S, indicates the input is set for an
S-Video signal.

Press

B

to select EXT1, EXT2 or EXT3.

EXT1 displays equipment connected to Scart 1.

EXT2 displays equipment connected to Scart 2.

EXT3 displays equipment connected to Input 3 on
the front of the TV.

To return to TV mode press

B

again or one of the

numbered buttons.

Use the Input Selection if the TV does not switch over

automatically.

Input selection

INPUT signal selection

OUTPUT signal selection for Scart 2

1

1

1

2

2

If the colour is missing try the alternative setting.

Feature menu

EXT2 Input

z

Video

x

Ext2 Output

z

EXT1

x

Horizontal Position

z x

Width

z x

Vertical Position

z x

Height

z x

Panel Lock

z

Off

x

Automatic Format

z

Off

x

Blue Screen

z

On

x

EXIT To Exit

fe

Select

z x

Adjust

Feature menu

EXT2 Input

z

AV

x

Ext2 Output

z

EXT1

x

Horizontal Position

z x

Width

z x

Vertical Position

z x

Height

z x

Panel Lock

z

Off

x

Automatic Format

z

Off

x

Blue Screen

z

On

x

EXIT To Exit

fe

Select

z x

Adjust
