Electrical
Data
Table ED-2 — Unit Wiring With Electric Heat (Single Point Connection) — 208/230 Volts Single and Three Phase
Standard Indoor Motor
Oversize Indoor Motor
To Use
Heater
Heater
Control
Max Fuse Size or
Max Fuse Size or
Tons
With
Model No.
KW Rating
1
Stages
MCA
Max Circuit Breaker
2
MCA
Max Circuit Breaker
2
208/230 Volts Single Phase
BAYHTRR105A
3.8/5.0
1
48.8/52.2
60/60
51.2/54.6
60/60
3
WSC036A1
BAYHTRR110A
7.5/10.0
2
71.3/78.3
80/80
73.7/80.7
80/90
BAYHTRR114A
10.4/13.8
2
88.4/98.1
90/100
90.8/100.5
100/110
BAYHTRR105A
3.8/5.0
1
62.4/65.7
80/80
64.5/67.8
80/80
4
WSC048A1
BAYHTRR110A
7.5/10.0
2
84.9/91.9
100/100
87.0/94.0
100/110
BAYHTRR114A
10.4/13.8
2
102.0/111.6
110/125
104.1/113.7
110/125
BAYHTRR118A
13.2/17.6
2
119.2/131.4
125/150
121.3/133.5
125/150
BAYHTRR105A
3.8/5.0
1
71.3/74.7
90/100
73.0/76.4
100/100
5
WSC060A1
BAYHTRR110A
7.5/10.0
2
93.8/100.8
110/110
95.5/102.5
110/110
BAYHTRR114A
10.4/13.8
2
111.0/120.6
125/125
112.7/122.3
125/125
BAYHTRR118A
13.2/17.6
2
128.2/140.3
150/150
129.9/142.0
150/150
208/230 Volts Three Phase
BAYHTRR306A
4.5/6.0
1
34.7/37.1
40/45
37.1/39.5
45/45
3
WSC036A3
BAYHTRR312A
9.0/12.0
2
50.3/55.2
60/60
52.7/57.6
60/60
BAYHTRR318A
13.1/17.4
2
64.4/71.4
70/80
66.8/73.8
70/80
BAYHTRR306A
4.5/6.0
1
40.0/42.4
50/50
42.1/44.5
50/50
4
WSC048A3
BAYHTRR312A
9.0/12.0
2
55.6/60.5
60/70
57.7/62.6
60/70
BAYHTRR318A
13.1/17.4
2
69.7/76.7
70/80
71.8/78.8
80/80
BAYHTRR306A
4.5/6.0
1
48.2/50.6
60/60
49.9/52.3
60/60
5
WSC060A3
BAYHTRR312A
9.0/12.0
2
63.8/68.7
70/80
65.5/70.4
70/80
BAYHTRR318A
13.1/17.4
2
78.0/85.0
80/90
79.7/86.7
80/90
BAYHTRR323A
17.3/23.0
2
92.6/101.7
100/110
94.3/103.4
100/110
BAYHTRS309A
6.8/9.0
1
55.7/59.3
60/60
57.0/60.6
60/70
6
WSC072A3
BAYHTRS318A
13.5/18.0
1
79.0/86.3
80/90
80.3/87.6
90/90
BAYHTRS327A
20.3/27.0
2
102.5/113.4
110/125
103.8/114.7
110/125
BAYHTRS336A
27.0/36.0
2
126.0/140.4
150/150
127.3/141.7
150/150
BAYHTRS309A
6.8/9.0
1
64.9/68.5
80/90
69.3/72.9
90/90
7½
WSC090A3
BAYHTRS318A
13.5/18.0
1
88.3/95.5
100/100
92.7/99.9
100/100
BAYHTRS327A
20.3/27.0
2
111.8/122.7
125125
116.2/127.1
125/150
BAYHTRS336A
27.0/36.0
2
135.8/149.7
150/150
139.7/154.1
150/175
BAYHTRT318A
13.5/18.0
1
97.3/104.6
100/110
104.4/111.7
110/125
10
WSC120A3
BAYHTRT327A
20.3/27.0
2
120.8/131.7
125/150
127.9/138.8
150/150
BAYHTRT336A
27.0/36.0
2
144.3/158.7
150/175
151.4/165.8
175/175
BAYHTRT354A
40.6/54.0
2
191.2/180.3
200/200
198.3/187.4
200/200
Notes:
1. Heater kw ratings are at 208/240 for 208/230V unit
2. HACR type circuit breaker per NEC.
