TECHNICAL SPECIFICATIONS
General
Standards IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX
IEEE 802.3ab 1000Base-T
IEEE 802.3z 1000Base-SX/LX (Mini-GBIC)
IEEE 802.3x Full Duplex Flow Control
Protocol CSMA/CD
Data Transfer Rate Ethernet: 10Mbps (half duplex), 20Mbps (full-duplex)
Fast Ethernet: 100Mbps (half duplex), 200Mbps (full-duplex)
Gigabit Ethernet: 2000Mbps (full-duplex)
Topology Star
Network Cables 10BASET: 2-pair UTP Cat. 3, 4, 5; up to 100m
100BASE-TX: 2-pair UTP Cat. 5; up to 100m
1000BASE-T: 4-pair UTP Cat. 5; up to 100m
Number of Ports 24 10/100Mbps Auto-MDIX RJ45 ports
2 pairs 10/100/1000Mbps Auto-MDIX RJ45 port and 1000Base Mini-
GBIC slot
Physical and Environmental
AC inputs 100-240V AC, 50-60 Hz internal universal power supply
Power Consumption 11Watts (Max)
Temperature Operating: 0 ° ~ 40° C, Storage: -10° ~ 70° C
Humidity Operating: 10% ~ 90%, Storage: 5% ~ 90%
Dimensions 440 x 140 x 44 mm (W x H x D)
EMI: FCC Class A, CE Mark Class A, VCCI Class A
Safety: cUL (UL60950), CB (IEC60950)
40
Performance
Transmits Method: Store-and-forward
Filtering Address
Table:
8K entries per device
Packet
Filtering/Forwarding
Rate: 10Mbps Ethernet: 14,880/pps
100Mbps Fast Ethernet: 148,800/pps
1000Mbps Gigabit Ethernet: 1,488,000/pps
MAC Address
Learning:
Automatic update
Transmits Method: Store-and-forward
RAM Buffer: 256Kbytes per device
