CONTROL LOCATIONS
E9
L R
1. Adjustable Camera Lens
2. Handle
3. Monitor
4. Karaoke Function button
5. Karaoke Function “-” button
6. CHANNEL UP button
7. POWER LED
8. POWER button
9.
10. CHANNEL DOWN button
Volume DOWN button
11. Volume UP button
12. DVD Door
13. Loudspeaker
14. VIDEO IN 2 Jack
15. MIC 2 Jack
16. MIC 1 Jack
17. Jacks Door
18. Handle
19. Karaoke Function “+” button
20. Model Number 21. Remote Sensor
22. Function Selector (TV/AV/DVD)
23. MENU button
24. STOP button
25. OPEN/CLOSE button
26. PLAY/PAUSE button
27. Loudspeaker
28. AUDIO IN 2 (L) Jack
29. Headphone Jack
30. AUDIO IN 2 (R) Jack
FRONT VIEW
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
21
22
23
24
25
26
27
28
29
19
20
30
18
