Toro SUPER RECYCLER 20055 User Manual
Page 7
3356-748 Rev A
Gear Case Assembly No. 108-8140
A2
Ref
Part No.
Qty. Description
Case-Gear
1
104-7619
1
Cover-Case, Gear
2
614668-03
1
Screw-HWH
3
32144-4
4
Ring-Retaining
4
32151-68
1
Washer-Flat
5
3256-24
1
Pin-Groove
6
3285-19
2
Nut-Lock
7
3296-5
1
Washer
8
36-4780
2
Washer-Thrust
9
36-4791
2
Bushing
10
60-8750
2
Bushing
11
60-8850
2
Shaft-Intermediate
12
614696
1
Pulley-Half
13
100-1176
2
Bearing-Ball
14
100-1048
1
Spacer
15
62-6660
1
Gear-19T Spur, 37T Bevel
16
104-1005
1
Gear-Pinion, Bevel
17
104-7667
1
Gear-30T
18
104-1004
1
Shaft-Output
19
108-8141
1
7
