SECTION 7: USING YOUR OUTDOOR COOKTOP
GENERAL BURNER INFORMATION
• Each burner is rated at 15,000 BTU on High.
• Choose a pan base to fit the flame size. The
flame should never extend beyond the base of
the pan.
• Never turn on a burner without removing the
cover.
• When not in use, place the stainless steel
cover over the grate.
USING THE BURNERS
1. Remove the burner cover.
2. Check that the burner caps are in the correct
position. Tab A on the cap fits notch B on the
base.
3. Put grate in position.
4. Follow Lighting Instructions on Page 12.
Igniter
TAB A
Ports
Porcelain
Enamel Cap
BURNER CAP
FIGURE 13 – Burner Base
NOTCH B
13
