Tyco Electronics M7200 - Manual (Page 23)

MM-011553-001, Rev. A
23
Menus and button function will vary depending upon system programming, radio
hardware, and optional configurations.
No V-TAC-related menus are displayed on non-V-TAC radios/control heads.
The “Vchan Menu” is only displayed if the V-TAC is in the SOI mode.
If a V-TAC is in an Extended Coverage mode (XCOV or XCOV-TG), the number of
portable radios (“clients”) connected to the V-TAC is displayed in the bottom line of the
dwell menu.
If a V-TAC is in Extended Coverage for a talk group (XCOV-TG), the selected talk
group and profile in use is displayed.
6.13 DUAL-TONE MULTI-FREQUENCY
Dual-Tone Multi-Frequency (DTMF) is the system used by touch-tone telephones. DTMF assigns a
specific tone frequency to each key so a microprocessor can easily identify its activation. The radio
supports DTMF with a system model control head (Figure 6-1). This allows for specific tasks such as
entering a user ID and password, or selective calling.
When a key on the DTMF keypad is pressed, the DTMF tone is played through the radio’s speaker.
6.14 KEYPAD COMMANDS (SYSTEM MODEL CONTROL HEAD)
To perform a command from the keypad, press the * key followed by one of the pre-set function keys as
follows:
Table 6-5: Keypad Function Commands
*0 Log-off command: *0## (logs the user off the system). See page 17 for additional information.
*1
Log-in command: *1 # ## (required for encryption). See page 16 for
additional information.
*4
Enter Scene of Incident Mode (SOI) on specified channel: *4## where LC is the
channel number that is being used as a SOI repeater and band is the number assigned to each
frequency band. For example, if LC 25 800 MHz (band 0) is being used for SOI, then enter
*4,25,#,0,#.
*4# Exit SOI Mode
*6 Select Default Profile: Selects the default profile as long as the radio is not voice registered.
*7
Initiate Selective Alert command: *7#[Choose Message]#. See page 32 for
additional information.
*8 Radio-to-Radio Call command: *8 # (PTT to dial).
*9
Public Switched Telephone Network (PSTN) Call command: *9 # (PTT to
dial). See page 33 for additional information.
*32
Begin Manual Encryption command: *32< Encryption Key of up to 16 Digits for 128-bit AES
or 17-32 digits for 256-bit AES># See page 37 for additional information.
*33 End Manual Encryption command.
