Table 6-4: Basic Menu Structure
Menu Name
Radio Displays
(top and bottom lines)
Usage Notes
To/From Dwell Display
registration, RF sync and
transceiver status codes
Engineering Display
(Menu may not be
available per
programming.)
bit-error rates
and RSSI data
Displays radio system connection data. For engineering use.
OFF/ON
Silent Emergency
“SilentEmerg”
Use to toggle Silent Emergency OFF/ON.
available modes
Operating Mode
(OTP, EDACS, etc.) “Mode Menu”
Use to choose an available mode. Press MENU and
confirm (Y/N) with and press MENU again.
current latitude and
longitude GPS Fix
“GPS Fix”
Radio’s current GPS latitude and longitude position scrolls
across top line of the display. Applies to GPS-equipped radios
only.
User ID # of user
currently logged in User ID
“User ID”
User’s identification/name scrolls across top line of the display
(if programmed).
Radio’s IP address
IP Address
“IP Address”
Radio’s Internet Protocol (IP) address scrolls across top line of
the display.
V-TAC operating mode
V-TAC Mode
“Vmode Menu”
Use to choose an available V-TAC operating mode.
V-TAC SOI channel V-TAC Channels
(Menu appears only if in
SOI mode.)
“Vchan Menu”
Use to choose an available V-TAC channel for Scene-
Of-Incident (SOI) mode communications.
station’s call sign
Station Identification
“Station ID”
Station’s identification/name scrolls across top line of the
display (if programmed).
“OFF”
Stealth Mode
“StealthMenu”
Use to turn enable. Press any button to disable.
“LOW”, “MEDIUM”,
“MEDHIGH”, “HIGH” Treble Level
“Treble Menu”
Use to choose speaker/headset treble level. Press
Select to return to dwell display.
“<< >>”
Display Brightness
“Bright Menu”
Use to dim or brighten backlighting. Press MENU to
return to dwell display.
“OFF”, “LOW”, “MED”,
“HIGH” Side Tone Level
“Side Menu”
Use to choose side tone level. Press MENU to return to
dwell display.
See Next Page
