Step 2: Cabinet Preparation
Figure 2
•
The cabinet cutout dimensions are shown in
Figure 1.
•
It is a good practice when the microwave oven
is installed at the end of a cabinet run, adja-
cent to a perpendicular wall or cabinet door,
to allow at least
1
/
4
" space between the side
of the trim and wall or door.
•
Your microwave oven can be installed into a
cabinet or wall by itself or above any of the
following Thermador wall ovens: C271, C301,
CM301, S301, SC301. Or, Thermador Warm-
ing Drawers WD27 and WD30 (see Figure 2).
•
Outlet can be located anywhere within the
shaded area as indicated in Figure 1.
Warming
Drawer
cutout
Microwave
cutout
1
-1
/
2
"
(38 mm)
➝
}
Microwave
Cutout
Top of
microwave
shelf
1
-3
/
4
"
(45
mm)
}
Thermador
single wall
oven
cutout
Figure 1
Outlet should be
in the shaded area.
➛
➛
4"
14"
4"
➛
➛
A
➝
➝
➝
➝
➛
➛
➛
➛
B
C
Trim Kits
Dimensions
Width (B)
MT30B
28
-1
/
2
"
±
1
/
16
"
MT27B
25
-1
/
2
"
±
1
/
16
"
Height (A)
All Trim Kits
17"
±
1
/
16
"
Depth (C)
All Trim Kits
24"
±
1
/
8
"
