Topfield TF 5100 PVR User Manual
Page 17
2.3 Rear panel connections
11
7
S-VIDEO
Super video output socket for the television
set.
8
TV
Audio and video output socket for the tele-
vision set.
9
VCR
Audio and video input / output socket for
the video cassette recorder or suchlike.
10
USB
USB port for firmware update and data trans-
fer.
11
RF OUT
Analog television output socket.
12
RF IN
Analog television input socket.
13
S/PDIF
Dolby digital output socket for the audio sys-
tem.
14
RS-232
Serial port for firmware update and data trans-
fer.
Table 2.3: Connectors specification
VIDEO
Composite video (CVBS) output
AUDIO
Left & right audio output
S-VIDEO
Super video (S-Video) output
TV
CVBS/S-Video/RGB/YUV video output
Left & right audio output
VCR
CVBS video output
Left & right audio output
CVBS/S-Video/RGB/YUV video input for bypass
Left & right audio input for bypass
S/PDIF
Dolby digital audio output
RS-232
115.2 kbps at maximum
USB
2.0
