POWER
Press and hold the Power
switch for about 3 seconds,
then release to power off.
IN/OUT KNOBS
The overall Input level is
adjusted via the knob in the
upper left corner of the G-
Force. The Input should aver-
age approx. -3 to -6 dB
on the Input meters.
Set your output level using the
Output knob.
CARD SLOT
The PCMCIA slot can be used
for storing and loading presets.
Use Type 1 PC Cards with a
minimum 64 KBytes of SRAM.
BILLBOARD
The Billboard of the G-Force is capable of
showing preset number and name, Tempo
and a global message that you can write
into the G-Force (refer to Billboard in the
Utility section). Both Tuner and Tempo use
the Billboard to display information as well.
Beneath the Billboard you will find four
indicators, displaying: Preset Edited,
incoming MIDI information, incoming Pedal
information and internal Overflow.
The two lower meters will indicate gain
reduction in the Compressor and Noise
Gate, but are also used as tuner indicators
when Tuner is active.
METERS
These meters indicate the
level of Left and Right
inputs.
The Input level of the G-
Force automatically opti-
mizes the signal to noise
ratio via a small relay in
the input section. You will
see a prompt on the dis-
play and may hear a small
click when the input gain
range is changed.
THE FRONT PANEL
