Television System
NTSC standard
Channel Coverage
VHF: 2 through 13
UHF: 14 through 69
Cable TV: Mid band (A-8 through A-1, A through I)
Super band (J through W)
Hyper band (AA through ZZ, AAA, BBB)
Ultra band (65 through 94, 100 through 125)
Power Source
120 V AC, 60 Hz
Power Consumption
144 W (average)
Audio Power
10 W + 10 W
Speaker Type
Two 6
×
12 cm
Video/Audio Terminals
S-VIDEO INPUT
Y : 1 V(p-p), 75 ohms, negative sync.
C : 0.286 V(p-p) (burst signal), 75 ohms
VIDEO/AUDIO INPUT
VIDEO: 1 V(p-p), 75 ohms, negative sync.
AUDIO: 150 mV(rms) (30% modulation equivalent,
22 k ohms or more)
ColorStream ® (component video) INPUT
Y : 1V(p-p), 75 ohms
P
R : 0.7 V(p-p), 75 ohms
P B : 0.7 V(p-p), 75 ohms
AUDIO: 150 mV(rms), 22 k ohms or more
VIDEO/AUDIO OUTPUT
VIDEO: 1 V(p-p), 75 ohms, negative sync.
AUDIO: 150 mV(rms) (30% modulation equivalent,
2.2 k ohms or less)
VARIABLE AUDIO OUTPUT
0–300 mV(rms) (30% modulation equivalent,
2.2 k ohms or less)
Appendix
Specifications
• Design and specifications are subject to change without notice.
WARNING: RISK OF ELECTRIC SHOCK !
Never attempt to service the TV yourself. Opening and removing the covers may expose you to dangerous voltage
or other hazards. Refer all servicing to a Toshiba Authorized Service Center.
Video/Audio Terminals (cont.)
HDMI INPUT:
HDMI 1.1 (type A) compliant
HDCP 1.1 compliant
E-EDID* 1.3 compliant
Supports DVI-D uncompressed, high-speed, digital
single-link input
Suggested scan rates: 1080i, 480p, 480i, 720p
HDMI Audio: 2-channel PCM; 16/20/24 bits
per sample; 32/44.1/48 kHz sampling frequency
Dimensions
Width 33-45/64 inches (856 mm)
Height 24-9/16 inches (624 mm)
Depth 23-15/32 inches (596 mm)
Mass
157 lbs (71.0 kg)
Supplied Accessories
Remote Control with 2 size “AA” alkaline batteries
Optional TV Stand
ST34W64
Exemptions
TACP/TCL are not liable for:
(1) damage caused by fires, natural disaster (such as thunder,
earthquake, etc.), acts by third person, accidents, owner’s
misuse, or use in other improper conditions;
(2) incidental damages (such as profit loss or interruption in
business, modification or erasure of record data, and so
forth) caused by use or inability to use of this product;
(3) damage caused by neglect of the instructions described in
the owner’s manual; and
(4) damage caused by misuse or malfunction through
simultaneous use of this product and the connected
equipment.
* E-EDID = Enhanced-Extended Display Identification
