GENERAL DESCRIPTION

The TOA M-1264 is a 19" rack-mountable stereo mixer with multiple inputs and outputs. Inputs can be expanded by

using the M-1212E expansion unit.

FEATURES

Six monaural inputs (expandable using the M-1212E), four stereo inputs and one auxiliary stereo input.

One each of output: stereo, group (L/R), stereo sum, monitor (L/R), AUX, and headphone.

A compressor built in each monaural input minimizes signal distortion caused when there is an extremely large

input. The activation of the compressor can be indicated by a compressor activation lamp.

Motorized stereo/group output volume controls can be remotely adjusted from a control device. The adjusted

control position is indicated on the control device.

The M-1212E can function as a sub-mixer because it has mixing outputs (stereo L/R, group L/R, AUX, and cue).

Phantom power (+24V DC) can be supplied to each monaural input.

A channel switch with an "easy-to-see" indicator provided for each input improves the signal-to-noise ratio and

simplifies operations.

4-step stereo/group send selection switch (stereo to group/group to stereo bus/group to post-stereo output

control/ OFF).

A 3-step input level selection switch (LINE/MIC/MIC (HPF)) allows selection of either a line or microphone

level input for each monaural input. The MIC (HPF) position cuts undesired frequencies using a highpass filter.

Electronically-balanced monaural input can be changed to a transformer-balanced input using an optional input

transformer.

Security cover.
