Tektronix PHASER 220E User Manual
Page 4
Note
In the next step, it is only necessary to remove the old engine control
board from a Phaser 200e or Phaser 200i Color Printer.
8.
Disconnect the wiring harnesses leading to the engine controlÊboard.
9.
Lift out the engine control board.
Card cage
Disconnect
harnesses
31865-02
Lift out
engine board
31865-03
