5
The LCD OSD allows you to set up and configure the LCD display:
• To bring up the LCD OSD main menu, press the button marked Menu.
• Use the and buttons to navigate and make adjustments; after navigating to a setting choice, use
the Menu button to bring up the adjustment screen.
• When making adjustments, increases the value; decreases the value.
• When you are satisfied with your adjustment, press Exit to return to the OSD main menu.
• When all your adjustments have been made, press Exit to close the LCD OSD.
An explanation of the settings is given in the table below:
Auto Adjust Automatically configures all the settings for the LCD panel to settings
that the OSD considers the optimum values.
Brightness Adjusts the background black level of the screen image.
Contrast Adjusts the foreground white level of the screen image.
Phase Adjusts the vertical size of the screen image.
Clock Adjusts the horizontal size of the screen image.
H-Position Positions the display area on the LCD panel horizontally (moves the display
area left or right).
V-Position Positions the display area on the LCD panel vertically (moves the
display area up or down).
Color Adjustment Adjusts the color quality of the display. You can adjust the “warmth” value,
color balance, etc. The Adjust Color selection has a further submenu that lets
you fine tune the RGB values.
Language Selects the language that the OSD displays its menus in.
Recall Resets the adjustments on all menus and submenus to their factory default
settings.
LCD OSD Configuration
