Specifications
The 350 specifications are detailed in brief and then subsequently in more detail.
In the detailed version, we attempt to explain the significance of each
specification.
The correlation between published specifications and sonic quality can be
unreliable. A list of numbers reveals virtually nothing. All technical
measurements must be subject to qualitative as well as quantitative
interpretation. M easurements of the 350 reveal excellent results by any
standards. Tested at 115V and 230V after a 10 minute warm up period.
Specifications
In Brief
Rated Power Output:.................................................................. 350W
RMS
into 8Ω
( continuous, per channel, both channels driven from 20Hz-20kHz at < 0.020% THD)
................................................................................................. 600W
RMS
into 4Ω
( continuous, per channel, both channels driven from 20Hz-20kHz at < 0.035% THD)
Frequency Response:.......................................................... 5Hz – 40kHz ±0.25dB
Total Harmonic Distortion
( THD+N)
Typically:.....................................................................0.004%, @ 1kHz into 8Ω
20Hz to 20kHz: .......................................................................<0.020%, into 8Ω
Voltage Gain: .............................................................................................. 30.7dB
Dynamic Headroom
( rated with music)
:............................................................>1.1dB
Voltage Swing: ............................................................................................197V
p-p
M aximum Current Output:............................................................80A per channel
Damping Factor:.................................................................>700, @ 1kHz into 8Ω
Signal to Noise Ratio
Rated Output ( unweighted) :............................................................................ 100dB
Input Sensitivity
Unbalanced:.............................................................................................1.5V
RM S
Balanced: .............................................................................................±0.78V
RMS
Input Impedance
Unbalanced:.................................................................................................22kΩ
Balanced: ....................................................................................................3.3kΩ
Smoothing Capacitance:...........................................................................60,000µF
(30,000µF per channel)
Driver Stage:............................................................................................... Class A
Output Stage: ........................................................................................Class A/AB
Audio Inputs
Unbalanced:.....................................................................1 pair RCA connectors
Balanced: ......................................................................... 1 pair XLR connectors
Audio Outputs:..................................2 pairs of speaker binding posts per channel
Other Connections
1 x IEC AC mains input receptacle
1 x 3.5mm “mini” jack for master remote input (5 – 12V DC)
1 x 3.5mm “mini” jack for slave remote output (12V DC)
