EO1-11099
- 39 -
Replacing the Paper Roll
3
Set the paper roll ready for print. Refer to
Chapter "8. Installing the Paper Roll".
1
To remove the Printer Cover, insert the
Printer Cover/Drawer key to the Printer
Cover Lock, and then turn it 90
°
clockwise.
2
If the printer is used for Journal, hold down
the [FEED] key to wind up the printed
portion of paper, then cut the paper as
shown in the figure. Hold down the
[FEED] key again to advance the remain-
ing paper end.
If the printer is used for Receipt, cut the
paper roll as shown in the figure. Then
hold down the [FEED] key to advance the
remaining paper end.
The wound-up portion of the paper (when
used for Journal) can easily be removed
from the Reel by pulling it sideways.
14. Maintenance
WARNING!
Care must be taken not to injure yourself with the paper cutter.
