* 0 dB = 1 V
Note: The design and specifications are subject to change without notice for improvement.
Power cord (2 m or 6.56 ft) .................................................. 1
Rack mounting bracket ........................................................ 2
Bracket mounting screw (M4 x 16) ...................................... 4
Removable terminal plug (3 pins) ........................................ 2
Terminal cover ..................................................................... 1
Terminal cover mounting screw (M4 x 8) ............................ 2
Volume control cover YA-920 .............................................. 2
• Accessories
120 V AC, 60 Hz
404 W (rated output), 208 W (UL60065)
CH 1, CH 2 input: –20 dB* or 0 dB* (switchable), 10 kΩ, electronically-balanced,
removable terminal block (3 pins),
CH 1 mode ON/OFF switch (ON: CH 1 to All ch, OFF: Each ch)
Speaker output CH 1, CH 2: 60 W, 83 Ω x 2, BTL output (70 V line),
M4 screw terminal,
distance between barriers: 9 mm (0.35")
20 – 20,000 Hz, 0.08% T.H.D.
20 – 20,000 Hz (–3 dB, +1 dB)
At Input short, 20 – 20,000 Hz, Input level selector switch in 0 dB* position
Output volume min.: 105 dB, Output volume max.: 97 dB
0.008%
(22 kHz LPF, 1 kHz, rated output, input level selector switch in 0 dB* position)
Output disconnected for approx. 5 s after switching power on
Power (blue) x 1, Protect (red) x 2, Peak (red) x 2, Signal (green) x 2
Forced air cooling (fan speed: variable with temperature)
–10°C to +40°C (14°F to 104°F)
35% to 80% RH (no condensation)
Panel: Aluminum, hair-line, black
Case: SECC, black, paint
420 (w) x 107.6 (h) x 406 (d) mm (16.54" x 4.24" x 15.98")
10 kg (22.05 lb)
Power Source
Power Consumption
Input
Output
Power Band Width
Frequency Response
S/N Ratio
Total Harmonic Distortion
Function
LED Indicator
Ventilation System
Operating Temperature
Operating Humidity
Finish
Dimensions
Weight
16.2. P-9120DH
